Clayton Power LPS II 3000 – 160Ah

Clayton Power LPS II 3000 – 160Ah

Regular price £2,999.00
Regular price Sale price £2,999.00
Sale Sold out

Pick up available, usually ready for collection in 2 to 3 days

Clayton Power LPS II 2500 – 1 kWh

The Clayton Power LPS II is an all in one solution to the complex task of managing campervan electrics. This unit handles all of the 230v needs through an RDC protected circuit. It also contains all of the 12v electrics that are required for a campervan.

Lithium-Ion Battery Power Supply Clayton Power - LPS II 160 AH-3000 W

Plug and go - You´ve got the power!

All in One built in 2 kWh Li-Ion battery, allowing you to charge quickly and efficiently from Alternator, Mains or Solar panels. With a built-in lithium battery the LPS is extremely compact and has a very long lifetime, but it is not possible to change the built-in lithium battery. There are currently more than 35,000 Clayton Power products in use across the UK and Europe.

The meaning of 2 kWh power.

The lithium battery capacity of 1 kWh means that you can run an application with a consumption of 1000 W in one hour, 500 W for two hours and 250 W for four hours. A 2 kWh battery has twice the capacity.
Example: Power tools 500 W x 1 hour + Light 150 W x 5 hours = 1,25 kWh

The number of cycles.

The battery can handle 2000 cycles – which is usually equivalent to 10 years of use.

Recharge time.

2 kWh lithium:

  • From 0-80% in about 120 mins from DC and mains
  • 2x faster recharging time with the supercharger – from 0-80% in one hour (only from alternator)
  • 400W recharges from solar, from 0-80%, in 240 mins (which is why solar is often used to reduce fuel consumption and for off-grid)
  • You can use mains, supercharger and solar in combination to recharge even faster


Model No. LPS2 3012-160 / CL2003
Battery type Li-Ion 12V – 160Ah
Battery chemistry LiFePO4
Battery capacity 160Ah (2112Wh)
Battery available capacity 134Ah (1900Wh)
AC Input voltage 207 VAC – 253 VAC
AC input frequency 45 Hz – 65 Hz
AC Input power (Mains Charge power) 750 W
Alternator Input Power 500 W / SC: 1000 W
AC Output voltage +- 10% 230 VAC pure sine wave
AC Output frequency 50 Hz
AC output power – Continuously (ambient temp) 2300 W
AC output power - 10 min. 3000 W
AC output power - Peak 5000 W
AC output power - AC In connected 3000 W
AC output efficiency (1000W) 94%
DC Input voltage 11.5 - 32 VDC
DC input current 45 A
DC input current with 1 external converter (efficiency) 90 A
DC output voltage 10-14.4 VDC
DC output charge current – Continuously 90 A
DC output discharge current – Continuously 180 A
DC output discharge current – 1 min. 350 A
Solar input charging power (max.) 400W
Solar input voltage 15 – 50 VDC
Solar input charging current (max.) 15 A
Input signals (5) C1, C2, M12 x 3
Output signals (4) C2 & M12 x 3
Self-discharge rate per month < 5%
Self consumption - Operating mode, Only DC Output active < 1 W
Self consumption - Operating mode, inverter and DC Output in with > 50W 30 W
Connection 230VAC Neutrik and Schuko
Connection C1 / C2 M4
Connection DC input M8
Connection DC output M8
Cooling Forced air (fan)
Operating temperature (output will be limited below 0°C and ab) -20°C~50°C
IP rating IP21
Product weight 27.5 kg
Product dimensions (HxWxL) 256 x 277 x 409mm
Jumpstart 40 A / 5 min
