Clayton Power LPS II 2000 – 100Ah

Clayton Power LPS II 2000 – 1 kWh

The Clayton Power LPS II is an all in one solution to the complex task of managing campervan electrics. This unit handles all of the 230v needs through an RDC protected circuit. It also contains all of the 12v electrics that are required for a campervan.

An LPS II 2000 has a built-in: 1 kWh Lithium-Ion Battery, 230 V Sine Wave Inverter, Booster (Charging from alternator), 400W MPPT Charge Controller (charging from solar panels), Intelligent charger (charging from mains)

Battery type Li-Ion 12V – 100Ah

Battery chemistry LiFePO4

Battery capacity 100Ah (1320Wh)

Battery available capacity 80Ah (1050Wh)

AC Input voltage 207 VAC – 253 VAC AC input frequency 45 Hz – 65 Hz

AC Input power (Charge power) 720 W

AC Output voltage +- 10% 230 VAC pure sine wave

AC Output frequency 50 Hz AC output power – Continuously (ambient temp) 1500 W

AC output power - 10 min. 2000 W AC output power - Peak 3000 W

AC output power - AC In connected 2300 W AC output efficiency (1000W) 94%

DC Input voltage 11,5 - 32 VDC DC input current 45 A

DC input current with 1 external converter (efficiency) 90 A

DC output voltage 10-14,4 VDC

Solar input charging power (max.) 400W Solar input voltage  15 – 50 VDC

Solar input charging current (max.) 15 A

Product weight 22,5 kg

Product dimensions (HxWxL) 256x277x409mm

Jumpstart 40 A / 5 min
