NDS PSM 150w Solenergy panel kit (1475mm x 676mm)
NDS PSM 150w Solenergy panel kit (1475mm x 676mm)
NDS PSM 150WP 360 Solenergy Panels + Sun Control Regulator + Gland + Cable Kit. Solenergy motorhome panels combine modern photovoltaic construction technology with a simple installation. The mounting brackets built into the frame of these ensures adequate distance from the anchoring surface, ensuring the necessary ventilation of the cells and adequate aerodynamics thanks to the rounded corners. Constant ventilation of the cells avoids any loss of performance even at high operating temperatures. This monocrystalline panel is made from high purity silicon cells coated with a Tedlar foil and textured tempered glass all enclosed in two sheets of EVA (Ethylene Vinyl Acetate).
The components used to coat the cells are designed to achieve maximum transmittance and transparency, plus the low iron content and anti-reflective coating increase efficiency to 18.05%. Special by-pass diodes protect the cells from overvoltages and allow the solar panel to continue working even in the event of shading and accidental breakage of the photovoltaic cells. The Solenergy 12V solar panels meet the most stringent quality and safety standards which can withstand the harshest environmental and pollution conditions.
This kit includes the solar panels, a regulator and a wiring kit with a free gland.
Number of cells: 32
Max Power: 150WP±3%
Features:
The special aluminium brackets integrated in the panel, with aerodynamic plastic side covers make the robust panel safe, easy and quick to install.
Each panel is equipped with a 6-metre bipolar connection cable with an all-weather protective outer sheath.
Architecture:
-Aluminium frame
-High transmittance glass: 91.5%
Height 1475mm (1.475m)
Width 676mm (0.676m)
Depth 60mm (0.06m)
Length Cable: 6m
Weight 12.5kg
Material High purity silicon coated with a tedlar foil and textured tempered glass all enclosed in two sheets of EVA (Ethylene Vinyl Acetate). Aluminium frame, High transmittance glass
Colour Black and Silver
Amps Description Short circuit current: 9.3A, Max power current: 8.71A
Contents Solar panel, regulator, wiring kit
